Como desmontar el teclado de una Acer Aspire One D257







operating System1  Genuine Windows® 7 Starter 32-bit
Genuine Windows® 7 Starter 32-bit / Android - dual OS
Processor / Speed1  Intel® Atom™ processor N570 (1 MB L2 cache, 1.66 GHz, DDR3 667 MHz, 8.5 W)

Intel® Atom™ processor N550 (1 MB L2 cache, 1.50 GHz, DDR3 667 MHz, 8.5 W)

Intel® Atom™ processor N455/N475 (512 KB L2 cache, 1.66/1.83 GHz, DDR3 667 MHz, 6.5 W) (for models with DDR3 support only)
Core Logic Chipset1  Mobile Intel® NM10 Express Chipset
System Memory1, 3,  Single-channel DDR3 SDRAM support with one soDIMM module4
Up to 1 GB of DDR3 system memory (for Windows® 7 Starter for small notebook PCs)
Up to 2 GB of DDR3 system memory (for other operating systems)
Display1  10.1" SD 1024 x 600 (WSVGA) resolution, high-brightness (200-nit) LED-backlit TFT LCD
Mercury-free, environment-friendly
Graphics1  Intel® Graphics Media Accelerator 3150 (Intel® GMA 3150), with 64 MB of dedicated system memory, supporting Microsoft® DirectX® 9
Dual independent display support
16.7 million colors
External resolution / refresh rate:5
VGA port up to 1600 x 900: 60 Hz
MPEG-2/DVD decoding
Audio  High-definition audio support
Two built-in stereo speakers
MS-Sound compatible
Built-in microphone
Storage  2.5" (9.5 mm) 250/320/500 GB1, 6,
Multi-in-1 card reader supporting:
Secure Digital™ (SD) Card, MultiMediaCard™ (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Storage cards with adapter: miniSD™, microSD™, Memory Stick Duo™, Reduced-Size Multimedia Card (RS-MMC), Memory Stick PRO Duo™
Communication  Acer Video Conference1, featuring:
Acer Crystal Eye webcam
WLAN:1, 8, 9,
Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
Supporting Acer SignalUp™ wireless technology
WPAN:1
Bluetooth® 3.0+HS (for Windows® 7 only)
WWAN:1, 8, UMTS/HSPA at 850/900/1900/2100 MHz and quad-band GSM/GPRS/EDGE at 850/900/1800/1900 MHz, upgradable to 7.2 Mb/s HSDPA and 5.7 Mb/s HSUPA (for 3G model)

LAN: Fast Ethernet
Input and Control  84-/85-/88-key full-size Acer FineTip keyboard, 93% of full-size keyboard, with international language support
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
I/O Ports  Multi-in-1 card reader
Three USB 2.0 ports
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software11  Productivity
Acer ePower Management
Acer eRecovery Management
Adobe® Flash® Player 10.1
Adobe® Reader® 9.1
AUPEO! (US only)
eSobi™
Barnes & Noble Desktop Reader (US only)
Bing™ Bar
Microsoft® Office 2010 preloaded (purchase a product key to activate)12
Microsoft® Office Starter 201013
New York Times Reader (US only)
NOOK for PC (US only)
Norton™ Online Backup
Security
McAfee® Internet Security Suite Trial14
MyWinLocker® (except China, Hong Kong)
Gaming
Oberon GameZone1 (except US, Canada, China, Hong Kong, Korea)
WildTangent®1 (US, Canada only)
Communication and ISP
Acer Crystal Eye
Acer Video Conference Manager1
Microsoft® Silverlight™
Skype™
Windows Live™ Essentials 20111
Web links and utilities
Acer Identity Card
Acer Registration
Acer Updater
Customized Internet Explorer® 8
eBay® shortcut 2009 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
Netflix shortcut (US only)
Dimensions / Weight1  256.5 (W) x 184 (D) x 24 (H) mm (10.17 x 7.28 x 1.01 inches)
1.30 kg (2.87 lbs.)2 with 6-cell battery pack
1.20 kg (2.65 lbs.)2 with 3-cell battery pack
Power1  Product Safety Electric Appliance and Materials (PSE) certified for battery pack
2-pin 40 W Acer MiniGo AC adapter:
93.2 (W) x 32.2 (D) x 42.5 (H) mm (3.66 x 1.26 x 1.67 inches)
180 g (0.39 lbs.)2 with 250 cm DC cable
Battery
24 W 4400 mAh 3-cell Li-ion battery pack
Battery life: 4 hours10
48 W 4400 mAh 6-cell Li-ion battery pack
Battery life: 8 hours10
Eco Standards  ENERGY STAR®
WEEE
RoHS
Mercury free
Color options  Aquamarine, Dark Chocolate, Seashell White
Specifications vary depending on model.
Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
